1. Key Advantages
Zero water hammer design
Spring-assisted closing technology, low impact force when the valve is closed, effectively eliminating pipeline water hammer phenomenon, protecting the pump and precision equipment.
Ultra-low flow resistance optimization
Straight-through flow path design, flow resistance reduced by 40%, flow coefficient (Cv value) increased by 30%, energy saving and consumption reduction.
Lifetime maintenance-free
316L stainless steel stem + self-lubricating bushing, coefficient of friction <0.1, resistant to 5 million openings and closings, trouble-free operation for more than 10 years.
Flexible installation
Compact structure (length 30% shorter than traditional valves), 40% lighter weight, space and bracket cost savings, support for narrow space piping.
2. Technical Specifications
|
Parameters |
Standard Configurations |
Extended Options |
|
Body Material |
304/316 Stainless Steel (CF8/CF8M) |
316L (Medical Grade), WCB Carbon Steel |
|
Sealing Material |
Stellite Cobalt Cemented Carbide |
PTFE/Flexible Graphite (Low Temperature) |
|
Nominal Diameter |
DN15-DN200 (Standard) |
DN300 (customized) |
|
Pressure Rating |
PN16 (1.6MPa) |
PN42 (high-pressure type) |
|
Temperature Range |
-29℃~+425℃ (standard) |
-196℃~+540℃ (extreme conditions) |
|
Connection |
Flange (GB/T9113) |
Butt-welding/threading (ASME B16.25) |
|
Certifications |
ISO 9001, RoHS |
FDA, 3-A (sanitary) |
3. Industry Applications
Oil & Energy
- Backflow prevention for oil pipelines (Hydrogen sulfide corrosion resistant, PN40 high pressure design).
- Boiler steam system (temperature resistance 540 ℃, zero leakage to ensure safety).
Chemical and Pharmaceutical
- Strong acid media transportation (316L valve body resistant to nitric acid, acetic acid).
- GMP aseptic pipeline (mirror polishing Ra ≤ 0.8μm, no dead space design).
Water treatment and electric power
- Power station cooling water system (spring-assisted closure, waterproof hammer impact).
- Municipal water supply network (DN200 large caliber, low flow resistance and energy saving).
4. Customization Options
▸ Extreme working condition adaptation:
- Deep cold type: -196 ℃ liquid nitrogen environment (special sealing package).
- High temperature type: 540 ℃ steam conditions (alloy steel valve body).
▸ Intelligent upgrade:
- Valve position sensor (4-20mA signal output, interlock control).
- Explosion-proof certified actuator (Ex d IIC T6).
▸ Sanitary Certification:
- 3-A/FDA compliant polished, supports CIP/SIP cleaning.
