1. Technical Specifications (Technical Specifications)
|
Parameter items |
Standard configuration |
Extended options |
|
Body Material |
304/316 Stainless Steel (CF8/CF8M) |
316L (Medical Grade), Carbon Steel (Industrial) |
|
Thread Standard |
G (BSPP), R (BSPT), NPT (American Standard) |
Customized Special Threads (e.g. UNF) |
|
Pressure Rating |
PN16 (1.6MPa) |
PN25/PN40 (high pressure type) |
|
Temperature range |
-20℃~+180℃ (standard) |
+350℃ (high temperature sterilization type) |
|
Sealing materia |
PTFE/flexible graphite |
metal hard seal (high temperature and high pressure) |
|
Drive mode |
Manual (handwheel) |
Electric/pneumatic (explosion-proof type) |
|
Certifications |
ISO 9001, FDA (sanitary) |
3-A, ASME BPE (pharmaceutical) |
2. Industry Applications
- Chemical/Petroleum: Acid and alkali resistant, high pressure resistant, suitable for petroleum pipelines, chemical transportation.
- Food & Beverage: Sanitary polished (Ra≤0.8μm), FDA compliant, used in CIP cleaning system.
- Pharmaceutical/Bioengineering: 316L material, no dead space design, meet GMP aseptic requirements.
- Marine/Energy: Suitable for fuel oil, sliding oil, steam (≤400℃) and other marine pipelines.
3. Customization Options
▸ Special threads: BSP, NPT, metric threads and other custom processing.
▸ Material upgrade: 316L, titanium alloy, Hastelloy and other corrosion-resistant materials.
▸ Extreme working condition adaptation: deep cold (-50℃), high pressure (PN40), food grade certification.
